House solar system_Three Phase Solar System_TANFON solar power system, solar panel inverter, solar home system factory

Global Quality, African Roots. nearly 20 years of C&I solar project experience and 8 demonstration projects

available for viewing anytime, Tanfon has extensive industry experience and is worthy of your trust.

Our global service network—with 63 overseas engineers and 4 African warehouses—guarantees efficient, reliable

support worldwide.

One-stop solutions with localized technical training and competitive factory prices, help you maximize solar system

value at minimum cost.

House solar system

Households gain reliable, clean electricity for lighting, phone charging, fans, radios, TVs, and small appliances,

replacing expensive, dirty, and dangerous kerosene lamps, candles, and diesel generators —

(with full payback in 5–7 years)

and freeing money for food, school fees, or other needs. Better lighting extends productive hours: children study

up to two extra hours at night, improving education outcomes.

24-hour power, 0 electricity bills, 30 years of energy independence.

Solar Panel 1.Higher efficiency 23.22% 2. Strong anti-cracking advantage 30 years product warranty 3. half cell PERC solar panel(LonGi N type TopCon Solar Cell) ☀️Solar panels convert sunlight into electricity.	Solar Inverter > 5 years warranty(solar with IOT) > With built-in charge controller > Pure sine wave inverter > Use copper transformer; > 110V/120V/220V/230V/240VAC ☀️Command your solar energy: converting, optimizing, and managing your power in one.	Solar Battery 1.Free maintenance, service life 6-8 years 2.DOD 70% cycles 6000 times 3.The latest through-wall welding technology,more suitable for motor loads. ☀️Think of it as a giant solar power bank: store sunshine by day, use clean energy anytime	Panel rack > Slope Roof or Flat roof or Ground (option) > Including complete fittings > Wind load:55 m/s,snow load:1.5 kg/m2 ☀️Position panels. Maximize sun.


PV Combiner Box IP Rating: IP65 Rated Voltage: 1000VDC Input cable terminal: 4-6mm²	DC Cable & MC4 Connector Cross Section: 4mm2, 6mm2 Optional Rated Voltage:600VDC/1000VDC(TUV) Rated Current: 55A,70A Colors: Black For STD, Red Optional. Lifetime:≤25 Years	PV Tools Wire Cable Cutter & Stripper, MC3 MC4 Crimper MC4 Connectors Assembly Disassembly Tool	Monitoring System Open station supports one-click installation and registration;Problem support one-click dispatch and navigation; Safe operation, traceable logs, etc; Support full lifecycle data storage to ensure data security and reliability.

TANFON Solar System Solutions for House Configuration Table
Category	Specification	TANFON Hybrid-10KW	TANFON Hybrid-5KW	TANFON DEYE-16KW
System Capacity	Daily Power Generation	< 64 kWh	< 28.8 kWh	< 100 kWh
	Battery Storage Capacity	20.48 kWh	10.24 kWh	32.15 kWh
	Maximum Load Power	10 kW	5 kW	16 kW
Solar Array	Bifacial Panels (TFD600W Longi N-type TopCon)	18 pcs	8 pcs	28 pcs
	Panel Connection	6 in series × 3 parallel	8 in series (1 string)	7 in series × 4 parallel
	Panel Efficiency & Warranty	23.22% │ 30 years	23.22% │ 30 years	23.22% │ 30 years
Power Conversion	Hybrid Inverter Model	SUN-10K-SG02LP1-EU-AM3-P	SUN-5K-SG02LP1-EU	SUN-16K-SG01LP1-EU
	Max PV Input / MPPT Trackers	3 MPPT trackers	2 MPPT trackers	3 MPPT trackers
	MPPT Voltage Range	150–425 V	200–425 V	150–425 V
	AC Output	Single phase 220/230/240 V	Single phase 220 V	Single phase 220/230 V
	Inverter Warranty	5 years	5 years	5 years
Energy Storage	Lithium Battery Model	2 × TFES-S48200 (51.2 V / 200 Ah each)	1 × TFES-S48200 (51.2 V / 200 Ah)	2 × TFES-S48314 (51.2 V / 314 Ah each)
	Battery Warranty & Cycle Life	5 years │ ≥ 6000 cycles	5 years │ ≥ 6000 cycles	5 years │ ≥ 6000 cycles
Management & Mounting	Mounting Rack	1 set (adjustable, slope/flat/ground)	1 set (adjustable, slope/flat/ground)	1 set (adjustable, slope/flat/ground)
Cables & Accessories	PV Cable (reference)	4 mm² × 200 m	4 mm² × 100 m	4 mm² × 300 m
	Battery Cable + Breaker	2×35 mm² + 2×300 A switch box	16 mm² + 63 A switch	2×25 mm² + 250 A switch box
Packing	Wooden Box Packing	1 set	1 set	1 set
Warranty Summary	Solar Panels │ Battery & Inverter	30 years │ 5 years	30 years │ 5 years	30 years │ 5 years

Our C&I solar system uses German 5S production technology and intelligent generator control, enabling efficient and prolonged

operation.

Choose Tanfon – we are your trusted energy partner!

Military-grade inverter with built-in transformer，can 110% overload capacity, 2-hour fast recharge with 200A charging current and

100% three-phase load imbalance tolerance.

Equipped with military-grade system logic and supported by 25-year free predictive maintenance that cuts OPEX by 40%,

it delivers long-term reliability and cost-saving benefits for users.
With 20 years of industry experience and one-stop service, choosing Tanfon will help you save 80% on your electricity bills.

Complete solutions from 100kW to 5MW：
including 100kW, 150kW, 250kW, 500kW, 800kW, 1MW, 1.5MW, 2.5MW, and 5MW.
Wide Applications:
Supermarkets, Factories, Schools, Hospitals, Mining, Hotels & More
one-stop solution
＞On-site survey, design, product testing, installation, and commissioning.
＞5-year remote predictive maintenance and free online upgrades via our EMS.

TANFON one-stop solar solution

Contract signing

If you dare to cooperate with Tanfon Solar, I can guarantee that you will get products of the same quality as the government.

TANFON industrial and commercial solar energy systems can run stably 7*24 hours at 45℃ high temperature.
Welcome to Chad to visit 8MWH TANFON SOLAR government engineering quality demonstration solar storage system

The 1.8MWH community solar project in Congo is in production. If you also have a solar system project, please feel free to consult us.

Site survey

Our TANFON Africa team of 63 engineers hails from Nigeria, Kenya, South Africa, South Sudan, Chad, Congo, and Zimbabwe.

We specialize in on-site surveys, training, installations, maintenance, and project site visits.

Project Design

Tanfon Solar has been deeply rooted in the solar energy field for over 20 years, dedicated to providing global customers with

one-stop solutions from design and installation to maintenance. Our engineering team has traveled to more than 130 countries,

successfully delivering a series of landmark commercial and industrial projects, ranging from a 100KW telecommunication base station

in East Timor and a 500KW large supermarket in Papua New Guinea, to a 1MW/2MWH community microgrid in Congo and a 6.48MWH

government power plant in Chad.

EPC construction guidance service
1). Determine the installation direction of the solar panels.
2). Instruct how to hoist the equipment.
3). Supervise local installers to strictly follow the requirements to lay out the lines
Technical training
a. Teach on-site users the whole set of solar system power on and off training
b. Train troubleshooting, emergency methods, and maintenance methods.
C. Train product users
Irregular return visits
Chinese engineers will make online and on-site return visits to the project from time to time to ensure that on-site users understand

the product technology and usage technology of the solar system

TANFON Industrial & Commercial Demonstration Solar Project


Supermarkets Solar Power System (100kw-500kw)	Resorts Solar Power System (150kw-500kw)


Commercial Building Solar System (100kw-500kw)	Agri-Solar Systems (50kw-150kw)


Community Solar System (1mw-5mw)	House Solar System (10kw-50kw)

About TANFON

FAQ

1.	Are you struggling with constant production downtime due to unstable grid power?
	still worrying about factory blackouts? TANFON solar keeps production lines running.
2.	Is the initial investment budget holding you back from moving forward with the project?
	If the quote is beyond your expectations, let us know your target price so we can tailor a solution.
3.	Are you interested in solar but not quite ready to make a purchase decision this month?
	If it’s not the right time to buy yet, feel free to learn more now. We're always here for technical support.
4.	Are the logistics and international shipping fees making you hesitate on your investment?
	Concerned about high shipping costs? We can help evaluate better logistics and enhance your investment efficiency.
5.	Is your inability to meet delivery deadlines due to power outages hurting your reputation?
	With solar power, outages won't hurt delivery schedules, creating more profit opportunities.
6.	Do you want to know how solar power can directly impact your long-term business savings?
	Solar reduces energy bills and minimizes downtime losses. A one-time investment brings years of returns.
7.	Is the stress of managing fuel prices and generator maintenance distracting you from growth?
	As a business owner, equipment downtime is the worst. TANFON solar ensures stable production so you can focus on growth.

House solar system

15 years

24 hours

0 distance

House solar system

24-hour power, 0 electricity bills, 30 years of energy independence.

Solar Panel

Solar Inverter

Solar Battery

Panel rack

PV Combiner Box

DC Cable & MC4 Connector

PV Tools

Monitoring System
