10kw off grid batteryless solar system
10kw off grid batteryless solar system

10kw off grid batteryless solar system

TANFON BSP-10KW solar system Daily power generation: <93.6KWH Allowable max loads power : 10KW Qty Solar panel TFD600W half cell PERC solar panel(LonGi N type TopCon Solar Cell)  Vmp: 43.4

Place Of Origin: Foshan, Guangdong Province, China

BrandName: Tanfon Solar

MOQ: 1 set,Accpet OEM &ODM

Certificate: TUV, ETL, ISO, CE, RoHS

Payment: T/T, L/C, Paypal, Western Union

15 years

industry leading technology

24 hours

uninterruptible power supply

0 distance

online service

TANFON BSP-10KW solar system Daily power generation: <93.6KWH

Allowable max loads power : 10KW
Qty

Solar panel
TFD600W half cell PERC solar panel(LonGi N type TopCon Solar Cell)
Vmp: 43.44V  Voc: 51.54V  Imp: 13.81A  Isc:14.50A
Efficiency: 23.22%   Size: 2279*1134*30MM
Strong anti-cracking advantage 25 years product warranty
Connect way :each 7pcs in series,4 string.
28pcs

PV combiner
Model:H4T-240v Multiple PV strings inputs.
Simplify wiring between PV array and controller. Prevent hot spot effect,Reliable thunderstorm& surge protection
Product Size::400*425*145mm max circuit voltage: 1000V
1pcs

Batteryless inverter
Batteryless inverter:BTF10KW
DC voltage :260V-380V
MPPT controller input range:190V-240V
Ouput voltage:110V/220v/230v/240v 50hz or 60HZ
working without battery,only working when have sunshine time.
Size:785*580*1197mm  weight:3150KG
1pc

Panel rack
Slope Rooftop /Flat rooftop/ground
wind load:55m/s,snow load:1.5kn/m2
structure:Anodized Aluminum+stainless steel, Angle adjustable
(other type of rack can be customized as per client’s requirement )
1set

Cables

1)MPPT to battery 16mm2*10M
2)4mm2 PV cable 200M, (black+ red)
3)1set MC4 Tools ,
4)1set PV terminals and MC4
1set
