65KW OFF GRID SOLAR SYSTEM
65KW OFF GRID SOLAR SYSTEM

65KVA 65KW Solar Panel System Off Grid & Grid Tie System

The Latest Price Of 65KW 65KVA Solar Power System From The Factory Cost, High Quality Solar And Competitive Price, Three Phase Off Grid Solar Power System

Place Of Origin: Foshan, Guangdong Province, China

BrandName: TANFON

MOQ: 1 set,Accpet OEM &ODM

Certificate: TUV, ETL, ISO, CE, RoHS

Payment: T/T, L/C, Paypal, Western Union

15 years

industry leading technology

24 hours

uninterruptible power supply

0 distance

online service

65KVA 65KW Solar System Single phase solar, split phase solar, three phase solar optional



Tanfon Solar Manufacturer since 2007, serving 160 countries, solar panel, solar inverter, solar battery. Home Solar System, Industrial &Commercial Solar System.

Tanfon Supply: Free site survey, design, production, installation, maintenance with our sophiscaticated one-stop service.

For the products, Each set solar power system has power on&off test 100 times per hour.Each step of production is under strict quality control. Our products are qualified with CE, ROHS, ISO, SGS certification

For our project case: Our products have been sold to more than 120 countries, (solar home project,solar school project ,solar hospital project,solar farm project ,solar hotel project,solar air port project ,solar millitary project ,Solar energy water treatment equipment project,solar goverment project etc)

we have a professional installation team, which has been to 32 countries and regions ( Egypt, Bangladesh, Chad, Malaysia,Thailand,Ghana, Doha, East Timor state, Pakistan, kenya ,indonesia ,Dubai,Mozambique etc.) for installation service. We also win many good feedbacks from the customers.

For our Global service in Thailand,Malaysia,Senegal,Mozambique,will build 120 service centers all over the world. Give strong after-sales service in Local

Click View Solar Power  Installation Case



Solar Energy Ssytem Product Details



65KVA 65KW Solar Panel System Off Grid With Battery

65KVA 65KW Solar Panel System Off Grid With Battery

Solar Panel (Quantity: 150 pieces)

FS600W mono solar panel(poly optional)

Vmp: 38.39V       Voc: 47.13V       Imp: 9.25A

Size: 1956*992*40mm

Coated steel Glass: 3.2mm Tempered

Terminal block: IP65 with MC4 connector

Efficiency performance: 25 years 80 %, 20 year 85%, 10 years 90%. 25 years life time  (CE RoHS)

PV combiner (Quantity: 2 pieces)

Model: H6T-360v Multiple PV strings inputs

Simplify wiring between PV array and controller,

protections  to controller, Prevent hot spot effect

Wide range of DC input voltage

Reliable thunderstorm & surge protection

65KVA 65KW Solar Panel System Off Grid With Battery

65KVA 65KW Solar Panel System Off Grid With Battery

Solar Controller (Quantity: 2 pieces)

MPPT controller model: 360v/80A

Charging efficiency: 90%-95%,

Charging mode, intelligent control.

Temperature compensation,

Various protection functions

Solar Battery (Quantity: 110 pieces)

Capacity: 12V/200AH

Full sealed Solar power gel battery,

Service life: 6-8 years ,

Size: 522*240*219mm

65KVA 65KW Solar Panel System Off Grid With Battery

65KVA 65KW Solar Panel System Off Grid With Battery

Solar Inverter (Quantity: 1 piece)

Solar three phase Inverter power:T65kw/360v

Low voltage: 324V         High voltage: 426V

Charging efficiency; 90%-95%, with AC charger built-in, Protection against short-circuit,

Output: 220V 380V 415V 50/60HZ

Solar Panel Rack (Quantity: 1 set)

Slope Roof or Flat roof or Ground (option)

including complete fittings

wind load: 55m/s, snow load:1.5kn/m2

structure: Anodized Aluminum + stainless steel

65KVA 65KW Solar Panel System Off Grid With Battery

65KVA 65KW Solar Panel System Off Grid With Battery

Cables (Quantity: 1 set)

84pcs 16mm2*35CM battery cable

6pcs 16mm2*1M battery cable

4mm2 PV cable 300M

Terminals and MC4



If you want to have Solar Panel to generate energy and save cost about the electricity. If you need to have energy by solar panel system to works for house, farm, hotel, factory, hospital, office, school, airport, etc.

Please contact to us to discuss more details, we can support to you all you need with your requirement

Get 65KW Solar System Price Now

About Tanfon Solar Manufacturer

Learn more Tanfon feedback cases



Solar Power System Projects



Tanfon Airport Projects 60kw Solar System in Indonesia (click to know more details about this project)

65KVA 65KW Solar Panel System Off Grid With Battery

Why Choose Tanfon?

Quality:

Service:

Efficiency:

Tanfon Factory Picture



65KVA 65KW Solar Panel System Off Grid With Battery

65KVA 65KW Solar Panel System Off Grid With Battery



Solar Products FAQ



Q: What can be included for this system from TANFON?

A:This system includes:solar panels, PV array combiner,Solar inverter with MPPT solar controller build in, Gel free maintenance battery,solar panel rack,cables.,etc.

Q: Is the system solution always the same? Can I customize one?

A: No. We have professional teams making solutions for our clients. Solutions are mainly customized based on different sunshine time and power consumption. So the 1kw system may be with different configuration.

Q: Who arranges the shipping?

A: We could help you arrange the shipment, we have good service forwarder in Guangzhou.

Q: What is the lifetime of the solar power system?

A: Solar panel’s lifetime are 25 years, charger controllers 5~ 7 years, inverters 5~7 years, batteries 6~8 years.

Q: What can Tanfon supply?

A: Tanfon Supply: Free site survey, design, production, installation, maintenance of one-stop service.
