TANFON Lithium Battery Advantage:
Longer Cycle Life: Offers up to 15 times longer cycle life and 5 timeslonger float/calendar life than lead acid battery.
Lighter Weight: About 40% weight of a comparable lead acid battery, saveup to 60% in weight.
Quick Charge: Short charge time compared with lead acid battery.
Low Self-Discharge: Lower self-discharge compared with lead acid batterylonger storage time without recharging.
Superior Safety: Multi-protection methods built inside to protect the batteryfrom overcharge, over discharge and short circuit situatior
High Efficient: Higher round-trip energy efficiency of the average (92%)than lead acid battery 80% (discharge from 100% to 0% and back to 100%charged)
|
Model(TFES-S) |
48200 |
|
Nominal Battery Energy |
10.24kWh |
|
Nominal Capacity |
200AH |
|
Nominal Voltage |
48V |
|
Charging Cut -off vol |
58.4V |
|
Discharging End-off vol |
40V |
|
Weight |
95KG |
|
Dimension |
580*230*680mm |
|
Max.Power Charge/Discharge Current |
100A |
|
Rated Charge Current(A) |
50A |
|
Charging Temp, Range |
0~50℃ |
|
Discharging Temp, Range |
-10~50℃ |
|
Calendar Life [1] |
>1500Cycles |
|
Protection Level |
IP54 |
